Tial F38 Wastegate .5 Bar Spring (SILVER)

Tial F38 Wastegate .5 Bar Spring (SILVER)

Regular price $240.00 Sale

The TiAL F38 is the classic 2 bolt flange wastegate. We first produced the F38 back in 2001 and it's still going strong today. This wastegate has a 38mm valve - same as the MV-S, and its body is about an inch taller.

*Specifications*
* High temp NiCrFe based alloy is used for valve and 347SS valve housing will offer longer product life compared to competing designs.
* High temperature silicone Nomex reinforced actuator diaphragm.
* 17-7 PH Stainless Steel actuator spring gives consistent pressure at high temperature, resist "relaxing" at temperature to 900F (483C).
* Nitronic 60 Stainless Steel is used for the valve seat, and valve bushing.
* All Stainless Steel hardware.
* Mating weld flanges are 304L or 1018
* Color anodized aluminum actuator (Silver, Red, Blue, Purple, Black).

*Included with every Tial F38:*
* F38 Assembly
* F38 Valve Seat
* 2 TiAL Air Fittings
* 2 Mounting Bolts
